Ref No. |
GLM No. |
OEM No. |
Description |
Qty. |
1 |
51410 |
912441 |
Exhaust Manifold Assembly - STBD |
1 |
1 |
51420 |
912442 |
Exhaust Manifold Assembly - PORT |
1 |
2* |
31100 |
3852468 |
Gasket - Exhaust Manifold |
1 |
3* |
33810 |
909786 |
Gasket - Exhaust Elbow |
1 |
4 |
22280 |
764799 |
Cap |
1 |
5 |
21791 |
3853786 |
Clamp |
1 |
6 |
22487 |
3852467 |
Stud |
6 |
7 |
21248 |
3853404 |
Nut |
6 |
8 |
21493 |
309336 |
Lockwasher |
6 |
9 |
51320 |
909863 |
Exhaust Elbow Assembly |
1 |
10 |
21896 |
315713 |
Plug |
1 |
11 |
21753 |
3853397 |
Screw |
4 |
13 |
89220 |
912374 |
Exhaust Hose (Cobra) |
1 |
14 |
89230 |
3852742 |
Exhaust Hose (Cobra) |
1 |
15 |
01090 |
3852604 |
Clamp |
3&4 |
16 |
01200 |
984387 |
Clamp |
1 |
17 |
50730 |
909609 |
Elbow Tube - STBD (Stringer Mount) |
1 |
17 |
50740 |
909610 |
Elbow Tube - PORT (Stringer Mount) |
1 |
18 |
89221 |
909232 |
Exhaust Hose |
1 |
19 |
89223 |
909371 |
Exhaust Hose |
1 |
* Included with Manifolds No. 51410 & 51420 |
