Ref No. |
GLM No. |
OEM No. |
Description |
Qty. |
1 |
51480 |
3857656 |
Exhaust Manifold Assembly |
1 |
2* |
32170 |
3853412 |
Gasket - Exhaust Manifold |
1 |
3* |
33810 |
909786 |
Gasket - Exhaust Elbow |
1 |
4 |
22487 |
3852467 |
Stud |
6 |
5 |
21248 |
3853404 |
Nut |
6 |
6* |
13982 |
- |
Straight Fitting |
1 |
6A* |
13992 |
806608A02 |
Drain Plug Kit |
1 |
6B* |
80140 |
304174 |
O-Ring |
1 |
6C* |
13983 |
- |
Straight Fitting |
1 |
7* |
13970 |
3852538 |
Elbow Fitting |
1 |
8 |
51330 |
3857944 |
Standard Exhaust Elbow Assembly |
1 |
9 |
51337 |
3862627 |
Hi-Rise, Single-Piece Exhaust Elbow Assembly (1992-2006) |
1 |
9 |
51336 |
3889964 |
Hi-Rise, Single-Piece Exhaust Elbow Assembly (2007 & Up) |
1 |
10 |
22398 |
3852830 |
Screw |
4 |
11 |
22379 |
- |
Plug |
1 |
12 |
21896 |
315713 |
Plug |
1 |
13 |
01100 |
3853860 |
Clamp |
4 |
14 |
89224 |
3852696 |
Exhaust Hose |
1 |
15 |
50790 |
3853372 |
Exhaust Tube |
1 |
16 |
01090 |
3852604 |
Clamp |
4 |
17 |
89222 |
3863450 |
Exhaust Hose |
1 |
* Included with Manifold No. 51480 |
