| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
843934T03 |
|
|
|
|
HEADER KIT, Exhaust - Port, Includes Gasket Ref No 9 |
1 |
|
This Part is No Longer Available |
| 1 |
843933T03 |
|
|
|
|
HEADER KIT, Exhaust - Starboard, Includes Gasket Ref No 9 |
1 |
|
This Part is No Longer Available |
| 2 |
27-840940 |
|
|
|
|
GASKET, Exhaust Header |
2 |
|
2,5 |
| 3 |
10-821131 |
|
|
|
|
SCREW, (.375-16 x 1.00) |
16 |
|
|
| 4 |
22-806608A02 |
|
|
|
|
PLUG ASSEMBLY, (.500-13) Blue |
2 |
|
|
| 5 |
25-26802 |
|
|
|
|
SEAL |
2 |
25-8M2000926 |
|
| 6 |
843384A1 |
|
|
|
|
TAILPIPE ASSEMBLY, Port |
1 |
|
This Part is No Longer Available Without Intercooler Water Exit Please email and ask us for the service bulletin regarding this part |
| 6 |
842964A01 |
|
|
|
|
TAILPIPE ASSEMBLY, Starboard |
1 |
|
This Part is No Longer Available With Intercooler Water Exit Please email and ask us for the service bulletin regarding this part |
| 7 |
54-180763 |
|
|
|
|
CLAMP, Worm Gear |
4 |
|
|
| 8 |
32-8424181 |
|
|
|
|
HOSE, Molded |
2 |
|
|
| 9 |
27-842454 |
|
|
|
|
GASKET, Tailpipe |
2 |
|
2 |
| 10 |
11-82671110 |
|
|
|
|
NUT, (.250-20) |
2 |
11-842458 |
|
| 11 |
54-842456 |
|
|
|
|
CLAMP, Band |
2 |
|
|
| 12 |
10-842457 |
|
|
|
|
T BOLT, (.250-20) |
2 |
|
|
| 13 |
22-842453406 |
|
|
|
|
FITTING, Restrictor (.406) |
2 |
|
|
| 14 |
861776A2 |
|
|
|
|
PLATE KIT |
1 |
|
|
| 15 |
13-41471 |
|
|
|
|
LOCKWASHER, (.375) |
4 |
|
|
| 16 |
10-98794 |
|
676-9-78129 |
700-28300 |
525-10-98794 |
SCREW, (.375-16 x 1.00) |
4 |
|
|
| - |
27-843073A05 |
|
|
|
|
GASKET/SEAL SET, Engine Overhaul |
1 |
|
NOTE: See Gasket/Seal Set - Engine Overhaul Section For Complete Parts Listing |
