| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
735-802557T |
|
|
|
|
PISTON ASSEMBLY, Standard |
8 |
|
(Standard) (5.0L) |
| 1 |
735-802558T |
|
|
|
|
PISTON ASSEMBLY, .030 Oversize |
AR |
|
(.030 Oversize) (5.0L) |
| 1 |
735-835001T |
|
|
|
|
PISTON ASSEMBLY |
8 |
|
(Standard) (350) 4 |
| 1 |
735-835002T |
|
|
|
|
PISTON ASSEMBLY |
AR |
|
(.5MM Oversize) (350) |
| 1 |
735-879345T91 |
|
|
|
|
PISTON ASSEMBLY |
8 |
735-864175A3 |
(Standard) (6.2L) 1 |
| 2 |
39-802559 |
|
|
|
|
RING SET, Piston |
8 |
|
(Standard) (5.0L) 4 |
| 2 |
39-808570 |
|
|
|
|
RING SET, Piston |
AR |
39-802560 |
(.030 Oversize) (5.0L) |
| 2 |
39-8018611 |
|
|
|
|
RING SET, Piston |
8 |
39-801861T1 |
(Standard) (350) 4 |
| 2 |
39-835000 |
|
|
|
|
RING SET, Piston |
AR |
|
(.5MM Oversize) (350) |
| 2 |
39-864176A1 |
|
|
|
|
RING SET, Piston |
8 |
|
(Standard) (6.2L) 1 |
| 3 |
614-8164T |
|
|
|
|
CONNECTING ROD ASSEMBLY |
8 |
|
(5.0L/350) 4 |
| 3 |
614-862587A3 |
|
|
|
|
CONNECTING ROD ASSEMBLY |
8 |
|
(6.2L) |
| 4 |
10-85802 |
|
|
|
|
SCREW, (.375-24 x Special), Connecting Rod |
16 |
|
This Part is No Longer Available |
| 5 |
11-37493 |
|
|
|
|
NUT, (.375-24) |
16 |
|
|
| 5 |
11-862573 |
|
|
|
|
NUT (MX-6.2L) |
16 |
|
|
| 6 |
23-85701 |
|
|
|
|
BEARING |
8 |
|
(Pair-Standard) (5.0L/350) 4 |
| 6 |
23-85702 |
|
|
|
|
BEARING |
AR |
|
(Pair- .001 Undersize) (5.0L/350) |
| 6 |
23-85703 |
|
|
|
|
BEARING |
AR |
|
(Pair- .002 Undersize) (5.0L/350) |
| 6 |
23-85704 |
|
|
|
|
BEARING |
AR |
|
(Pair- .010 Undersize) (5.0L/350) |
| 6 |
23-85705 |
|
|
|
|
BEARING |
AR |
|
(Pair- .020 Undersize) (5.0L/350) |
| 6 |
849391T |
|
|
|
|
BEARING SET, Standard - 8 Pair |
1 |
31-849391 |
(6.2L) |
| 6 |
8M0050745 |
|
|
|
|
BEARING SET, (.001 Oversize) 8 Pair |
1 |
31-849392 |
(6.2L) |
| 6 |
8M0053548 |
|
|
|
|
BEARING SET, (.001 Undersize) 8 Pair |
1 |
31-849393 |
(6.2L) |
