| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| - |
1641-8294A19 |
|
|
|
|
GEAR HOUSING ASSEMBLY, Complete |
1 |
|
(1.50:1 - 1.65:1 Ratio) |
| - |
1641-8294J02 |
|
|
|
|
GEAR HOUSING ASSEMBLY, Complete |
1 |
|
(SEACORE)(1.50:1 - 1.65:1 Ratio) |
| - |
1641-8294A16 |
|
|
|
|
GEAR HOUSING ASSEMBLY, Complete |
1 |
|
(1.81:1 - 2.00:1 - 2.20:1 Ratio) |
| - |
1641-8294J01 |
|
|
|
|
GEAR HOUSING ASSEMBLY, Complete |
1 |
|
(SEACORE)(1.81:1 - 2.00:1 - 2.20:1 Ratio) |
| 1 |
1641-8294A14 |
|
|
|
|
GEAR HOUSING ASSEMBLY, Basic |
1 |
|
|
| 1 |
1641-8294J00 |
|
|
|
|
GEAR HOUSING ASSEMBLY, Basic |
1 |
|
(SEACORE) |
| 2 |
16-579203 |
|
|
|
|
STUD, (.437-14/.437-20 x 2.060) |
2 |
|
|
| 3 |
25-33465 |
|
|
|
|
O-RING |
1 |
|
|
| 4 |
26-455771 |
|
|
|
|
SEAL |
1 |
|
|
| 5 |
26-805344 |
|
|
|
|
SEAL, (.625 Outside Diameter) |
1 |
|
|
| 6 |
31-86754T |
|
|
|
|
BEARING ASSEMBLY, Roller |
1 |
|
|
| 7 |
22-8M0058389 |
|
|
|
|
PLUG KIT, Drain - Magnetic, Magnetic |
2 |
22-67892A06 |
|
| 8 |
26-830749 |
|
|
|
|
SEAL |
1 |
|
|
| 9 |
76214Q5 |
|
|
|
|
ANODE KIT |
1 |
|
|
| 10 |
13-806210 |
|
|
|
|
LOCKWASHER, (.437) |
1 |
|
|
| 11 |
10-90084 |
|
|
|
525-10-90084 |
SCREW, (.437-14 x 1.500) |
1 |
|
|
| 12 |
12-861854 |
|
|
|
|
WASHER, (.453 x .750 x .032) Stainless Steel |
1 |
|
|
| 13 |
54163 |
|
|
|
|
RETAINER |
1 |
|
|
| 13 |
8M2000346 |
|
|
|
|
RETAINER |
1 |
|
(SEACORE) |
| 14 |
15-92914A1 |
|
|
|
|
SHIM KIT |
AR |
|
|
| 15 |
31-99328A1 |
|
|
|
|
BEARING ASSEMBLY, Tapered Roller |
1 |
31-66668A1 |
|
| 16 |
45-888434A1 |
|
|
|
|
DRIVESHAFT ASSEMBLY |
1 |
45-812561A2 |
|
| 17 |
31-815901 |
|
|
|
|
RACE, Bearing |
1 |
|
|
| 18 |
31-86748A1 |
|
|
|
|
BEARING ASSEMBLY, Tapered Roller |
1 |
|
|
| 19 |
14-86739 |
|
|
|
|
TAB WASHER |
1 |
|
|
| 20 |
15-86749A1 |
|
|
|
|
SHIM KIT |
AR |
|
|
| 21 |
23-92916 |
|
|
|
|
SPACER |
1 |
|
|
| 22 |
25-20826 |
|
|
700-82280 |
525-25-20826 |
O-RING, (2.230 x .139) |
1 |
|
|
| 23 |
88243A3 |
|
|
|
|
COUPLING ASSEMBLY |
1 |
|
|
| 24 |
53-88242 |
|
|
|
|
RING, Retaining |
1 |
|
|
| 25 |
43-41656T |
|
|
|
|
GEAR, (16/27), Pinion |
1 |
|
(1.81:1 - 2.00:1 - 2.20:1 Ratio) |
| 25 |
43-827304T |
|
|
|
|
GEAR, (18/25), Pinion |
1 |
|
(1.50:1 - 1.65:1 Ratio) |
| 26 |
12-805068 |
|
|
|
|
WASHER, Pinion Gear |
1 |
|
|
| 27 |
10-808027 |
|
|
|
|
SCREW, Pinion Gear |
1 |
|
|
| 28 |
15-55499A1 |
|
|
|
|
SHIM ASSEMBLY |
AR |
|
|
| 29 |
31-54038A1 |
|
|
|
|
BEARING ASSEMBLY, Tapered Roller |
1 |
|
|
| 30 |
44-62820T1 |
|
|
|
|
PROPELLER SHAFT |
1 |
|
|
| 31 |
31-54036A1 |
|
|
|
|
BEARING ASSEMBLY, Tapered Roller |
1 |
|
|
| 32 |
43-41657T |
|
|
|
|
GEAR, DRIVE |
1 |
|
(1.81:1 - 2.00:1 - 2.20:1 Ratio) |
| 32 |
43-827303 |
|
|
|
|
GEAR, DRIVE |
1 |
|
(1.50:1 - 1.65:1 Ratio) |
| 33 |
860323 |
|
|
|
|
RING, Thrust |
1 |
|
|
| 34 |
23-66093T |
|
|
|
|
RING, Load |
1 |
|
|
| 35 |
25-34821 |
|
|
|
|
O-RING |
1 |
|
|
| 36 |
863913A04 |
|
|
|
|
CARRIER ASSEMBLY, Bearing |
1 |
62813A4 |
|
| 36 |
863913A14 |
|
|
|
|
CARRIER ASSEMBLY, Bearing |
1 |
|
(SEACORE) |
| 37 |
31-54042T |
|
|
|
|
BEARING, Roller |
1 |
|
|
| 38 |
26-814242 |
|
|
|
|
SEAL, Oil, Fish-Line Cutter |
1 |
|
|
| 38 |
26-821092 |
|
|
|
|
SEAL, Oil |
1 |
|
|
| 39 |
28-30281 |
|
|
|
|
KEY |
1 |
|
|
| 40 |
14-54167 |
|
|
|
|
TAB WASHER |
1 |
|
|
| 41 |
14-34817 |
|
|
|
|
TAB WASHER |
1 |
|
|
| 42 |
11-82671127 |
|
|
|
|
PROP NUT, (1.00-14) Brass |
1 |
|
|
| 43 |
10-90085 |
|
|
|
|
SCREW, (.4375-14 x 2.75) |
1 |
|
|
| 44 |
13-47659 |
|
|
|
|
LOCKWASHER, (.437) |
1 |
|
|
| 45 |
12-861854 |
|
|
|
|
WASHER, (.453 x .750 x .032) Stainless Steel |
2 |
|
|
| 46 |
11-35053 |
|
|
|
|
NUT, (.437-20) |
2 |
|
|
| 47 |
55074T |
|
|
|
|
THRUST HUB |
1 |
|
|
| 48 |
12-55073A2 |
|
|
|
|
WASHER ASSEMBLY |
1 |
|
|
| 49 |
12-55072 |
|
|
|
|
WASHER |
1 |
|
|
| - |
26-76868A04 |
|
|
|
|
SEAL KIT, Gear Housing |
1 |
26-76868A2 |
|
| - |
888761Q01 |
|
|
|
|
ANODE KIT, Aluminium (Bravo II) |
AR |
888761A1 |
|
| - |
888760Q03 |
|
|
|
|
ANODE KIT, Magnesium (Bravo II) |
AR |
888760A1 |
|
