| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| - |
842064A02 |
|
|
|
|
DRIVELINE KIT, NXT1 - Complete |
1 |
|
|
| - |
84-8M3000325 |
|
|
|
|
HARNESS ASSEMBLY, Extension |
1 |
|
|
| - |
84-843203A04 |
|
|
|
|
HARNESS ASSEMBLY, Extension |
1 |
|
|
| - |
45-842089T |
|
|
|
|
SHAFT, Input |
1 |
45-842089 |
|
| - |
842090 |
|
|
|
|
RETAINER, Input Shaft |
1 |
|
|
| - |
10-41350 |
|
|
|
|
SCREW, (.437-14 x 2.50) Stainless Steel |
1 |
|
|
| - |
12-842922 |
|
|
|
|
WASHER, (.450 x .750 x .060) Stainless Steel |
1 |
|
|
| - |
NSS |
|
|
|
|
NOT SOLD SEPARATE, Installation Instructions |
1 |
|
This Part is not sold separately |
| - |
842064A01 |
|
|
|
|
TRANSOM KIT, NXT1 Driveline |
1 |
|
|
| - |
16-57933 |
|
|
|
|
STUD, (.437-14/.437-20 x 2.190) |
4 |
|
|
| - |
12-842922 |
|
|
|
|
WASHER, (.450 x .750 x .060) Stainless Steel |
4 |
|
|
| - |
11-34933 |
|
676-9-72004 |
|
|
NUT, (.437-20) Stainless Steel |
4 |
|
|
| - |
842064T01 |
|
|
|
|
HOUSING, Transom Support |
1 |
842064001 |
|
| - |
45-842112 |
|
|
|
|
SHAFT, Input |
1 |
|
|
| - |
23-8M0005859 |
|
|
|
|
SLEEVE |
1 |
|
|
| - |
53-8M0005874 |
|
|
|
|
RING, Snap |
1 |
|
|
| - |
22-328022 |
|
|
|
|
PLUG, Pipe (.125-27) Brass |
3 |
|
|
| - |
25-846366 |
|
|
|
|
O-RING, (4.860 x .120) |
1 |
|
|
| - |
847322A1 |
|
|
|
|
COVER ASSEMBLY, Input Shaft |
1 |
|
|
| - |
26-846496 |
|
|
|
|
SEAL |
1 |
|
|
| - |
31-847395T1 |
|
|
|
|
BEARING SET, Cup And Cone |
1 |
|
|
| - |
53-847323 |
|
|
|
|
RING, Retaining |
1 |
|
|
| - |
8M0050789 |
|
|
|
|
SPACER |
1 |
847321 |
|
| - |
31-846477A1 |
|
|
|
|
BEARING SET, Cup And Cone |
1 |
|
|
| - |
15-846430A1 |
|
|
|
|
SHIM SET |
1 |
|
|
| - |
26-846497 |
|
|
|
|
SEAL |
1 |
|
|
| - |
10-825427 |
|
|
|
|
SCREW, (.437-14 x 1.250) Stainless Steel |
4 |
|
|
| - |
12-45176 |
|
|
700-28420 |
|
WASHER, (.453 x .812 x .105) Stainless Steel |
4 |
|
|
