# PART NUMBER DESCRIPTION QTY.
1 421-FA-16 Adapter -6 JIC Swivel T 316 SS 2
2 421-FA-6 Adapter -6 JIC Swivel 90° 316 SS 2
3 421-FA-33 Adapter -6 JIC Swivel 45° 316 SS  4
4 421-BT-1 Bulkhead Tube Assembly -6 JIC Straight Polished 304 SS 2
5 421-HO-6 Hose Assembly -6 JIC x 18.000” Hose Length 20” End to End 4
6 421-HO-1 Hose 5/16” HP Field Attach Steel Clad Braid Black Cover 360"
7 421-FA-3 Hose Fitting -6 JIC to 5/16” HP Field Attach 316 SS Nut Stem NPB Collar 4
8 421-FA-35 Hose Fitting Mandrel -6 JIC 1
9 421-SR-8-1-13 Steer Ram Assembly 2
10 421-AEC-17 Steer Cap Kit Bravo 2 Ear 3.250” Clevis Pin Centers 1.000” Center Hole Black 2
11 421-TB-37 Tie Bar Kit for Steer Caps 1
12 421-TB-22 Transom Bracket Kit RH Reverse Polished 316/304 SS 1
13 421-TB-32 Transom Bracket Kit LH Reverse Polished 316/304 SS 1
