| 1 |
0032 |
OEM: 525-32-8M2021553 |
HOSE Port Manifold to Distribution Fitting |
|
1 |
|
| 2 |
0032 |
4285069 |
HOSE (44.00 Inches Bulk) Starboard Manifold to Distribution Fitting
|
(Cut to 22 Inches) |
1 |
|
| 3 |
0032 |
OEM: 525-32-8M2019570 |
HOSE Thermostat Housing to Port Manifold |
|
1 |
|
| 4 |
0032 |
OEM: 525-32-8M2018584 |
HOSE Thermostat Housing to Starboard Manifold |
|
1 |
|
| 5 |
0032 |
8623175 |
HOSE Cylinder Block Drain to Distribution Fitting |
(Port - 24 Inches, Starboard - 15 Inches) |
2 |
|
| 6 |
0032 |
OEM: 525-32-8M2023367 |
HOSE Thermostat Housing to Distribution Housing |
|
1 |
|
| 7 |
0032 |
OEM: 525-32-863781 |
HOSE Distribution Housing to Fuel Cooler |
|
1 |
|
| 8 |
0032 |
OEM: 525-32-863490 |
HOSE Distribution Housing to Distribution Fitting |
|
1 |
|
| 9 |
0022 |
OEM: 525-22-864621A1 |
FITTING ASSEMBLY Distribution |
|
1 |
|
| 10 |
0032 |
OEM: 525-32-8M2021613 |
HOSE Fitting to Fitting |
|
1 |
|
| 11 |
0032 |
OEM: 525-32-8M2018851 |
HOSE ASSEMBLY Thermostat Housing to Circulation Pump |
|
1 |
|
| 12 |
0032 |
OEM: 525-32-8M2020273 |
HOSE Check Valve to Fuel Cooler |
|
1 |
|
| 13 |
0021 |
OEM: 525-21-864206A1 |
CHECK VALVE ASSEMBLY |
|
1 |
|
| 14 |
0032 |
OEM: 525-32-8M2020274 |
HOSE Y-Fitting to Check Valve |
|
1 |
|
| 15 |
0022 |
OEM: 525-22-8M2003728 |
Y-FITTING |
|
1 |
|
| 16 |
0032 |
OEM: 525-32-8M2004196 |
HOSE Cooler to Y-Fitting |
|
1 |
|
| 17 |
0032 |
OEM: 525-32-8M2012165 |
HOSE Y-Fitting to T-Fitting |
|
1 |
|
| 18 |
0022 |
OEM: 525-22-8M2014002 |
FITTING Tee, Red Alpha |
|
1 |
|
| 18 |
0022 |
OEM: 525-22-8M2014001 |
FITTING Tee, Green Bravo |
|
1 |
|
| 19 |
0032 |
OEM: 525-32-8M2012166 |
HOSE T Fitting to Port Elbow |
|
1 |
|
| 20 |
0032 |
OEM: 525-32-8M2012167 |
HOSE T Fitting to Starboard Elbow |
|
1 |
|
| 21 |
0032 |
OEM: 525-32-807661 |
HOSE Transom to Cooler |
Alpha |
1 |
|
| 22 |
0054 |
OEM: 525-54-815504216 |
CLAMP Worm Gear (1.56 Diameter) |
|
AR |
|
| 23 |
0054 |
OEM: 525-54-815504228 |
CLAMP Worm Gear |
|
AR |
|
| 24 |
0054 |
OEM: 525-54-815504232 |
CLAMP Worm Gear (2.50 Diameter) |
|
AR |
|
| 25 |
0054 |
OEM: 525-54-815504222 |
CLAMP Worm Gear (1.98 DIameter) |
|
AR |
|
| 26 |
0054 |
OEM: 525-54-815504212 |
CLAMP Worm Gear |
|
AR |
|
| 27 |
0032 |
OEM: 525-32-8M2020990 |
HOSE Sea Pump to Cooler |
Bravo |
1 |
|
| 28 |
0054 |
OEM: 525-54-815504224 |
CLAMP Worm Gear |
|
1 |
|
| NS |
0019 |
8079923 |
COVER Clamp |
|
AR |
|
