496 Mag HO Model - Serial 0W060000 Thru 0W309999 - Gasket Set Components (27-889924A02), Overhaul
Other Sub-Sections:
- Block, Camshaft and Pistons
- Block, Crankshaft, Oil Pump and Front Cover
- Cool Fuel System
- Cooling System, Fresh Water Components
- Cooling System, Raw Water Components
- Cylinder Head
- Drive Lube Reservoir Assembly
- Engine Cover
- Engine Mounts
- Exhaust Manifold, Elbow and Riser
- Flywheel Housing
- Fuel Module Components
- Gasket Set Components (27-883231A1), Engine
- Gasket Set Components (27-889924A02), Overhaul
- Intake Manifold
- Lifting Brackets and Wiring Harness
- Mercathode Kit
- Oil Pan and Drain System
- PCM and Bracket
- Power Steering
- Remote Oil System
- Seawater Pump
- Shift Bracket (Digital Throttle and Shift)
- Shift Bracket, Mechanical Shift
- Smart Craft Sensor and Harnesses
- Starter and Alternator
- Throttle Body, Digital Throttle-Shift
- Throttle Body, Mechanical Throttle-Shift
- Trim Pump and Motor Components
- Trim Pump Assembly (Complete)
- Water Drain System
Ref. | OEM Part # | Hardin # | Mallory # | GLM # | Other # | Description | Num Req. | Superceded From | Special Notes | |
- | 27-889924A02 | GASKET SET, Overhaul | 1 | |||||||
- | 25-32509 | O-RING, (.489 x .070) | 4 | |||||||
- | 26-42077 | SEAL | 3 | |||||||
- | 27-46820 | 676-9-61400 | 700-33760 | GASKET, Exhaust Manifold to Cylinder Head | 2 | |||||
- | 27-49955 | 676-9-60104 | 700-30370 | GASKET, Drain | 2 | |||||
- | 25-8071341 | SEAL | 1 | |||||||
- | 26-861947 | SEAL | 1 | |||||||
- | 26-862957 | SEAL, Oil Filter Adaptor | 1 | |||||||
- | 27-863112 | GASKET, Idle Air Valve | 1 | |||||||
- | 27-863215 | GASKET | 2 | |||||||
- | 27-863285 | GASKET, Air Valve | 1 | |||||||
- | 26-865066 | SEAL, Heat Exchanger to Crossover | 2 | |||||||
- | 27-879150064 | GASKET | 1 | |||||||
- | 27-881603001 | GASKET, Circulating Pump | 2 | |||||||
- | 27-881604 | GASKET, Front Cover | 1 | |||||||
- | 26-881608001 | SEAL, Rear Crankshaft | 1 | |||||||
- | 26-881613001 | SEAL, Front Crankshaft | 1 | |||||||
- | 27-881612 | GASKET, Oil Pan | 1 | |||||||
- | 27-881620001 | GASKET, Cylinder Head to Crossover | 2 | |||||||
- | 27-881622 | GASKET, Cylinder Head Cover | 2 | |||||||
- | 26-881637T | SEAL, Valve Stem Oil | 16 | |||||||
- | 27-895235 | GASKET SET, Intake Manifold and Valley | 1 | |||||||
- | 27-881631 | GASKET, Cylinder Head | 1 |
