496 Mag EC HO Model - Serial 1A066166 Thru 1A350440 - Gasket Set Components, Overhaul
Section Drawing: (Hover or click to view larger)
Other Sub-Sections:
- AXIUS Steering, Fluid Filter (HP) 1A349743 and Up, Gen I
- AXIUS Steering, Fluid Filter (Non-HP) 1A349742 and Below, Gen I
- AXIUS Steering, High Pressure Filter Conversion Kit, Gen I
- AXIUS Steering, Hoses (HP Filter) 1A349743 and Up, Gen I
- AXIUS Steering, Hoses (Non-HP Filter) 1A349742 and Below, Gen I
- AXIUS Steering, Hydraulic Pump and Reservoir,Gen I
- AXIUS Steering, Oil Cooler and Bracket, Gen I
- Block, Camshaft and Pistons
- Block, Crankshaft, Oil Pump and Front Cover
- Cool Fuel System, SN 1A349419 and Below
- Cool Fuel System, SN 1A349420 and Above
- Cooling System, Fresh Water Components
- Cooling System, Raw Water Components, Port
- Cooling System, Raw Water Components, Port (AXIUS)
- Cooling System, Raw Water, Starboard (1A349419 and Below)
- Cooling System, Raw Water, Starboard (1A349420 and Above)
- Cylinder Head
- Drive Lube Reservoir Assembly
- Engine Cover
- Engine Mounts
- Exhaust Manifold
- Exhaust System Components
- Flywheel Housing
- Fuel Module Components - Bravo (1A349419 and Below)
- Fuel Module Components - Bravo (1A349420 and Above)
- Gasket Set Components, Engine
- Gasket Set Components, Overhaul
- Intake Manifold
- Jackshaft Main Kit
- Lifting Brackets and Wiring Harness
- Mercathode Kit
- Oil Pan and Drain System
- PCM and Bracket
- Remote Oil System
- Seawater Pump
- Shift Bracket, Digital Throttle Shift - Axius
- Shift Bracket, Mechanical Shift
- SmartCraft Sensor and Harnesses
- Starter and Alternator
- Steering Components
- Throttle Body, Digital Throttle-Shift
- Throttle Body, Mechanical Throttle-Shift
- Trim Pump and Motor Components
- Trim Pump Assembly, Complete
- Water Drain System
| Ref. | OEM Part # | Hardin # | Mallory # | GLM # | Other # | Description | Num Req. | Superceded From | Special Notes |
| - | 27-889924A03 | GASKET SET, Overhaul | 1 | ||||||
| - | 25-32509 | O-RING, (.489 x .070) | 4 | ||||||
| - | 26-42077 | SEAL, Swivel Tube | 3 | ||||||
| - | 27-49955 | 676-9-60104 | 700-30370 | GASKET, Drain | 2 | ||||
| - | 27-8M2018049 | GASKET, Cylinder Head to Exhaust Manifold | 2 | 27-8M2000886 | |||||
| - | 27-8M2003931 | GASKET, Elbow | 2 | ||||||
| - | 25-8071341 | SEAL | 1 | ||||||
| - | 26-861947 | SEAL, Crossover | 1 | ||||||
| - | 26-862957 | SEAL, Oil Filter Adaptor | 1 | ||||||
| - | 27-863215 | GASKET, Throttle Body | 2 | ||||||
| - | 27-863285 | GASKET, Air Valve | 1 | ||||||
| - | 26-865066 | SEAL, Heat Exchanger to Cossover | 2 | ||||||
| - | 27-866390 | GASKET, Collector | 2 | ||||||
| - | 27-881603001 | GASKET, Circulating Pump | 2 | ||||||
| - | 27-881604 | GASKET, Front Cover | 1 | ||||||
| - | 26-881608001 | SEAL, Rear Crankshaft | 1 | ||||||
| - | 26-881613001 | SEAL, Front Crankshaft | 1 | ||||||
| - | 27-881612 | GASKET, Oil Pan | 1 | ||||||
| - | 27-881620001 | GASKET, Cylinder Head to Crossover | 2 | ||||||
| - | 27-881622 | GASKET, Cylinder Head Cover | 2 | ||||||
| - | 26-881637T | SEAL, Valve Stem Oil | 16 | ||||||
| - | 27-895235 | GASKET SET, Intake Manifold to Valley | 1 | ||||||
| - | 27-881631 | GASKET, Cylinder Head, Port | 1 | ||||||
| - | 27-879150064 | GASKET, Cylinder Head, Stoarboard | 1 |
