Bravo Three - Serial 0F730000 Thru 0M100000 - Stern Drive Unit Chart (Diesel)

Section Drawing: (Hover or click to view larger)

Untitled Document
Note: FOR REPLACEMENT OF DRIVESHAFT HOUSING ASSEMBLY, COMPLETE AND GEAR HOUSING ASSEMBLY, COMPLETE
Ref. OEM Part # Hardin # Mallory # GLM # Other # Description Num Req. Superceded From Special Notes
- 5232100LT         END MODEL, DIESEL BRV 1 DRV 1998 (1.36:1 Ratio) 1 5-5232100LS (BRAVO I)
- 5232200LT         END MODEL, DIESEL BRV 1 DRV 1998 (1.50:1 Ratio) 1 5-5232200LS (BRAVO I)
- 5232300LT         END MODEL, DIESEL BRV 1 DRV 1998 (1.65:1 Ratio) 1 5-5232300LS (BRAVO I)
- 5332200LT         (1.50:1 Ratio) 1 5332200LS (BRAVO II)
- 5332300LT         (1.65:1 Ratio) 1 5332300LS (BRAVO II)
- 5332400LT         (1.81:1 Ratio) 1 5332400LS (BRAVO II)
- 5332600LT         STERNDRIVE (2.00:1 Ratio) 1 5-5332600LS (BRAVO II)
- 5332500LT         STERNDRIVE (2.20:1 Ratio) 1 5-5332500LS (BRAVO II)
- 5-5442100LT         STERNDRIVE (1.36:1 Ratio) 1 5-5442100LS This Part is No Longer Available (BRAVO III)
- 5-5442200LT         STERNDRIVE (1.50:1 Ratio) 1 5-5442200LS This Part is No Longer Available (BRAVO III)
- 5-5442300LT         STERNDRIVE (1.65:1 Ratio) 1 5-5442300LS This Part is No Longer Available (BRAVO III)
- 5-5442400LT         STERNDRIVE (1.81:1 Ratio) 1 5-5442400LS This Part is No Longer Available (BRAVO III)
- 5-5442600LT         STERNDRIVE (2.00:1 Ratio) 1 5-5442600LS This Part is No Longer Available (BRAVO III)
- 5-5442500LT         STERNDRIVE (2.20:1 Ratio) 1 5-5442500LS This Part is No Longer Available (BRAVO III)
- 5-5442700LT         STERNDRIVE (2.43:1 Ratio) 1 5-5442700LS This Part is No Longer Available (BRAVO III)
