| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
8M0060051 |
|
|
|
|
COMPRESSOR ASSEMBLY, Air |
1 |
|
|
| 2 |
1100-8M0060381 |
|
|
|
|
END CAP ASSEMBLY |
1 |
|
|
| 3 |
10-8M0045380 |
|
|
|
|
SCREW, (M8 x 50) |
1 |
|
|
| 4 |
25-67206001 |
|
|
|
|
O-RING |
1 |
|
|
| 5 |
25-67206001 |
|
|
|
|
O-RING |
1 |
|
|
| 6 |
10-85593920 |
|
|
|
|
SCREW, (M6 x 20) |
4 |
|
|
| 7 |
653-833146T06 |
|
|
|
|
CONNECTING ROD ASSEMBLY |
1 |
|
|
| 8 |
NSS |
|
|
|
|
Piston Assembly |
1 |
|
Not Sold Separate |
| 9 |
53-8348101 |
|
|
|
|
RING, Lock |
2 |
|
|
| 10 |
835088A10 |
|
|
|
|
REED PLATE ASSEMBLY |
1 |
|
|
| 11 |
25-67207 |
|
|
|
|
O-RING, (3.489 x .070) |
2 |
|
|
| 12 |
25-832804 |
|
|
|
|
O-RING, (2.739 x .070) |
1 |
|
|
| 13 |
26-828225 |
|
|
|
|
SEAL |
1 |
|
|
| 14 |
8M0073890 |
|
|
|
|
HEAD KIT, Compressor |
1 |
|
|
| 15 |
22-8307535 |
|
|
|
|
FITTING, Straight |
1 |
|
|
| 16 |
10-82127335 |
|
|
|
|
SCREW, (M8 x 35 MM) |
4 |
|
|
| 17 |
10-8M0037204 |
|
|
|
|
SCREW, Nylon, push in |
1 |
|
|
| 18 |
54-22875 |
|
|
|
|
CLIP |
1 |
|
|
| 19 |
22-996642 |
|
|
|
|
FITTING, Elbow 90 Degree (.125-27 x .250) Nylon |
1 |
|
|
| 20 |
21-428641 |
|
|
|
|
FITTING, Check Valve |
2 |
|
|
| 21 |
22-856744 |
|
|
|
|
FITTING |
1 |
|
|
| 22 |
22-16604 |
|
|
|
|
FITTING, Straight (.125-27) |
1 |
|
|
| 23 |
25-831985 |
|
|
|
|
O-RING, (.468 x .078) |
1 |
|
|
| 24 |
13536A14 |
|
|
|
|
SENSOR ASSEMBLY, Temperature |
1 |
|
|
| 25 |
137151 |
|
|
|
|
RETAINER |
1 |
|
|
| 26 |
10-81893414 |
|
|
|
|
SCREW, (M8 x 14) |
1 |
|
|
| 27 |
22-390721 |
|
|
|
|
PLUG, Pipe (.125-27) Brass |
1 |
|
|
| 28 |
10-85593920 |
|
|
|
|
SCREW, (M6 x 20) |
6 |
|
|
| 29 |
8M0051194 |
|
|
|
|
PULLEY |
1 |
843224 |
|
| 30 |
10-8M0045380 |
|
|
|
|
SCREW, (M8 x 50) |
4 |
|
|
| 31 |
12-884594 |
|
|
|
|
WASHER |
1 |
|
|
| - |
25-832804A03 |
|
|
|
|
O-RING KIT |
1 |
|
|
