| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
32-8M0054152 |
|
|
|
|
TUBING, (38.00 Inches Bulk), Cut to 24 Inches |
1 |
85606065 |
|
| 2 |
32-8M0054152 |
|
|
|
|
TUBING, (38.00 Inches Bulk), Cut to 18-1/2 Inches |
1 |
85606065 |
|
| 3 |
32-8M0054152 |
|
|
|
|
TUBING, (38.00 Inches Bulk), Cut to 15-1/2 Inches |
1 |
85606065 |
|
| 4 |
32-8M0054152 |
|
|
|
|
TUBING, (38.00 Inches Bulk), Cut to 24-1/2 Inches |
2 |
85606065 |
|
| 5 |
32-8M0054152 |
|
|
|
|
TUBING, (38.00 Inches Bulk), Cut to 27 Inches |
1 |
85606065 |
|
| 6 |
21-858805 |
|
|
|
|
CHECK VALVE |
6 |
|
|
| 7 |
69355 |
|
|
|
|
TIE STRAP, (5.50 Inches) |
AR |
|
|
| 8 |
54-816311T |
|
|
|
|
TIE STRAP, (8.00 Inches) |
AR |
|
|
| 8 |
56762 |
|
|
|
|
TIE STRAP, (4.00 Inches) |
AR |
|
|
| 9 |
32-892830053 |
|
|
|
|
HOSE, (24.00 Inches Braided) |
1 |
|
|
| 10 |
32-85583466 |
|
|
|
|
TUBING, (34.00 Inches Bulk), Cut to 32 Inches |
1 |
|
No Longer Available |
| 11 |
21-8781051 |
|
|
|
|
CHECK VALVE |
1 |
|
|
| 12 |
22-424254 |
|
|
|
|
FITTING |
1 |
|
|
| 13 |
32-8M0108355 |
|
|
|
|
HOSE, (57.00 Inches Bulk), Cut to 6 Inches |
1 |
830756109 |
|
| 14 |
NSS |
|
|
|
|
Cap |
2 |
|
|
| 15 |
32-875289 |
|
|
|
|
HOSE |
1 |
|
|
| 16 |
22-858955 |
|
|
|
|
CONNECTOR |
2 |
|
|
| 17 |
35-875284T01 |
|
|
|
|
FILTER, Oil - In Line |
1 |
875284001 |
|
| 18 |
32-875283 |
|
|
|
|
HOSE, (2.00 Inches) |
1 |
|
|
| 19 |
8M0063190 |
|
|
|
|
RESERVOIR ASSEMBLY |
1 |
833069T9 |
|
| 20 |
NSS |
|
|
|
|
Decal |
1 |
|
|
| 21 |
25-855362001 |
|
|
|
|
GROMMET |
3 |
855362 |
|
| 21 |
25-855362001 |
|
|
|
|
GROMMET |
3 |
|
|
| 22 |
12-49436 |
|
|
|
|
WASHER |
3 |
|
|
| 23 |
10-60411 |
|
|
|
|
SCREW, (.312-18 x 1.250) |
3 |
|
|
| 24 |
23-855364 |
|
|
|
|
BUSHING |
3 |
|
|
| 25 |
87-856156T02 |
|
|
|
|
SWITCH ASSEMBLY |
1 |
856156A2 |
|
| 26 |
10-58376 |
|
|
|
|
SCREW, (.164-18 x .375) |
1 |
|
|
| 27 |
12-72761 |
|
|
|
|
WASHER, (.203 x .562 x .060) Stainless Steel |
1 |
|
|
| 28 |
54-814634 |
|
|
|
|
CLAMP |
2 |
|
|
| 29 |
32-883357 |
|
|
|
|
CONDUIT |
1 |
|
No Longer Available |
| - |
61-883201A01 |
|
|
|
|
POWERHEAD ASSEMBLY |
1 |
|
No Longer Available |
