| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
11-35888 |
|
676-9-72001 |
700-21180 |
|
NUT, (.250-28) Stainless Steel |
4 |
|
|
| 2 |
12-35462 |
|
|
|
|
WASHER, (.2656 x .625 x .0625) Stainless Steel |
8 |
|
|
| 3 |
65939 |
|
|
|
|
COVER |
1 |
|
|
| 4 |
16-846386 |
|
|
|
|
STUD, (.250-28 x 1.120) |
4 |
|
|
| 5 |
11-840200 |
|
|
|
|
NUT, Special |
4 |
|
This Part is No Longer Available |
| 6 |
11-29598 |
|
|
|
|
NUT, (.250-28) Stainless Steel |
4 |
|
|
| 7 |
23-848120 |
|
|
|
|
SPACER |
4 |
|
|
| 8 |
11-859124 |
|
|
700-21161 |
|
NUT, (#10-32) Stainless Steel |
3 |
11-45812 |
|
| 9 |
12-30164 |
|
|
|
|
WASHER, (.192 x .375 x .0312) Stainless Steel |
3 |
|
|
| 10 |
859209A1 |
|
|
|
|
MODULE, Advance Solenoid |
1 |
|
|
| 11 |
12-30164 |
|
|
|
|
WASHER, (.192 x .375 x .0312) Stainless Steel |
6 |
|
|
| 12 |
16-30172 |
|
|
|
|
STUD (#10-32 x 1.1250) |
3 |
|
|
| 13 |
11-840199 |
|
|
|
|
NUT, Special |
3 |
|
This Part is No Longer Available |
| 14 |
825317A6 |
|
|
|
|
MODULE, Spark Advance |
1 |
|
This Part is No Longer Available |
| 15 |
23-67269 |
|
|
|
|
SPACER |
3 |
|
|
| 16 |
11-68219 |
|
|
|
|
NUT, (#10-32) Stainless Steel |
3 |
|
|
| 17 |
847923 |
|
|
|
|
BRACKET, Spark Advance Module |
1 |
|
|
| 18 |
10-76502 |
|
|
|
|
SCREW, (.190-32 x 1.880) |
3 |
|
|
| 19 |
32-77690 |
|
|
|
|
LOOM, (12.00 Inches x .250 Spiral Cut), Cut As Required |
AR |
|
|
| 19 |
32-77760 |
|
|
|
|
LOOM, (12.00 Inches x .500 Spiral Cut), Cut As Required |
AR |
|
|
| 20 |
84-93529A9 |
|
|
|
|
CABLE ASSEMBLY, Coil |
1 |
|
This Part is No Longer Available |
| 21 |
332-4895A8 |
|
|
|
|
COIL KIT |
1 |
|
|
| 22 |
37-41358 |
|
|
|
|
DECAL, Caution |
1 |
|
|
| 23 |
37-48100 |
|
|
|
|
DECAL, Thunderbolt |
1 |
|
This Part is No Longer Available |
| 24 |
23-848119 |
|
|
|
|
SPACER |
4 |
|
|
| 25 |
10-42813 |
|
|
|
|
SCREW (#10-32 x .385) |
1 |
|
|
| 26 |
13-26996 |
|
|
|
|
LOCKWASHER, (#10) Stainless Steel |
12 |
|
|
| 27 |
332-2986A27 |
|
|
|
|
SWITCHBOX ASSEMBLY |
1 |
|
|
| 28 |
11-68219 |
|
|
|
|
NUT, (#10-32) Stainless Steel |
11 |
|
|
| 29 |
16-848140 |
|
|
|
|
STUD (.250-20/.250-28 x 5.060) |
4 |
|
|
| 30 |
25-88033 |
|
|
|
|
GROMMET |
1 |
|
|
| 31 |
848079A1 |
|
|
|
|
COVER ASSEMBLY |
1 |
848079A2 |
This Part is No Longer Available |
| 32 |
10-66686 |
|
|
|
|
SCREW, (#10-32 x 1.00) |
2 |
|
|
| 33 |
88-11178A01 |
|
|
|
|
BREAKER, Circuit - 50 Ampere |
1 |
88-11178 |
This part is the replacement for 11178A01 however the mounting hole will need to be enlarged to make it work. |
| 34 |
11-61356 |
|
|
|
|
NUT, (#10-32) Reduced Hex |
2 |
|
|
| 35 |
10-818369 |
|
|
|
|
SCREW (.375-16 x 1.25 Special) |
1 |
|
This Part is No Longer Available |
| 36 |
12-856774 |
|
|
|
|
WASHER, (.406 x .750 x .105) Stainless Steel |
2 |
|
|
| 37 |
818811 |
|
|
|
|
BRACKET, Electrical Compartment |
1 |
|
This Part is No Longer Available |
| 38 |
16-818824 |
|
|
|
|
STUD, (.375-16/.375-24 x 1.590) |
1 |
|
|
| 39 |
16-818824 |
|
|
|
|
STUD, (.375-16/.375-24 x 1.590) |
1 |
|
|
| 40 |
12-856774 |
|
|
|
|
WASHER, (.406 x .750 x .105) Stainless Steel |
2 |
|
|
| 41 |
11-82671013 |
|
|
|
|
NUT, (.375-24) |
2 |
11-34932 |
|
| 42 |
691182 |
|
|
|
|
BRACKET, Electrical Mount |
1 |
|
This Part is No Longer Available |
| 43 |
25-47623 |
|
|
|
|
GROMMET |
1 |
|
|
| 44 |
37-72554 |
|
|
|
|
DECAL, Circuit Breaker |
1 |
|
|
| 45 |
25-57009001 |
|
|
|
|
GROMMET |
1 |
25-57009 |
|
| 46 |
10-358701 |
|
|
|
|
SCREW, (.375-16 x 2.00), Compartment To Flywheel Housing |
1 |
|
|
| 47 |
12-856774 |
|
|
|
|
WASHER, (.406 x .750 x .105) Stainless Steel |
1 |
|
|
| 48 |
25661T1 |
|
|
|
|
SOLENOID |
1 |
|
|
| 49 |
13-26992 |
|
|
|
|
LOCKWASHER, (.250) Stainless Steel |
2 |
|
|
| 50 |
10-73286 |
|
|
|
|
SCREW, (.250-20 x .500) Stainless Steel |
2 |
|
|
| 51 |
13-26993 |
|
|
|
|
LOCKWASHER, (.312) |
2 |
|
|
| 52 |
11-28770 |
|
|
|
|
NUT, (.312-24) Stainless Steel |
2 |
|
|
| 53 |
12-848136 |
|
|
|
|
WASHER, (.328 x .680 x .190), Used As Spacer |
2 |
|
|
| 54 |
12-843108 |
|
|
|
|
WASHER, (.330 x .560 x .060) Stainless Steel |
1 |
|
|
| 55 |
11-82670911 |
|
|
|
|
NUT, (.312-24) Stainless Steel, Brace To Cooler Cover |
1 |
11-35814 |
|
| 56 |
11-F1669 |
|
|
|
|
NUT, (#6-32) |
2 |
|
|
| 57 |
12-27882 |
|
|
|
|
WASHER |
4 |
|
|
| 58 |
10-12110 |
|
|
|
|
SCREW, (#6-32 x .750) |
2 |
|
|
| 59 |
79-8M0050399 |
|
|
|
|
MONITOR, Maintenance |
1 |
79-859000A2 |
|
| 60 |
84-849042A2 |
|
|
|
|
HARNESS ASSEMBLY, Engine |
1 |
|
|
| 61 |
26079A2 |
|
|
|
|
PLATE KIT, Wire Harness Mount |
1 |
|
|
| 62 |
10-15001 |
|
|
|
|
SCREW, (#8-16 x .875) |
4 |
|
|
| 63 |
54-78945 |
|
|
|
|
J CLAMP, Harness Support |
2 |
|
|
