| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
811575T |
|
|
|
MANIFOLD |
1 |
811575 |
7.4L BRAVO I & II |
| 2 |
10-37510 |
|
|
|
BOLT, (1.5 In.) |
14 |
|
7.4L BRAVO I & II No longer made, limited availability |
| 2 |
10-811577 |
|
|
|
BOLT |
2 |
|
7.4L BRAVO I & II |
| 1 |
72608T |
|
|
|
MANIFOLD |
1 |
72608 |
This Part is NLA from Mercruiser. |
| 2 |
10-802655 |
|
|
|
BOLT |
12 |
10-805612 |
7.4L BRAVO III |
| 2 |
10-805611 |
|
|
|
BOLT |
4 |
|
7.4L BRAVO III |
| 1 |
72608T |
|
|
|
MANIFOLD |
1 |
72608 |
This Part is NLA from Mercruiser.(7.4L BRAVO III) |
| 2 |
10-37510 |
|
|
|
BOLT, (1.5 In.) |
12 |
|
454 MAGNUM No longer made, limited availability |
| 2 |
10-805611 |
|
|
|
SCREW, (.375-16 x 1.750) |
4 |
10-811574 |
454 MAGNUM |
| 3 |
54-64628 |
|
|
|
LIFTING EYE |
1 |
|
|
| 4 |
10-34354 |
|
|
|
SCREW, (.375-16 x 1.50) |
2 |
|
|
| 4 |
16-806250 |
|
|
|
STUD |
2 |
|
|
| 5 |
11-32219 |
|
|
|
NUT, (.375-16) |
1 |
|
|
| 6 |
NSS |
|
|
|
NOT SOLD SEPARATE, STUD (GM #10092939) |
4 |
|
This Part is not sold separately 2 |
| 7 |
8M0050225 |
|
|
|
GASKET SET |
1 |
27-811644 |
(7.4L BRAVO I & II) 4 |
| 7 |
27-805722A1 |
|
676-9-61217 |
|
GASKET SET |
1 |
|
(7.4L BRAVO III & 454 MAGNUM) 5 |
| 8 |
34543 |
|
|
|
VALVE, Oil Bypass |
2 |
|
|
| 9 |
22-806242 |
|
|
|
CONNECTOR |
2 |
|
|
| 10 |
32-805987 |
|
|
|
HOSE |
1 |
|
|
| 11 |
54-815504412 |
|
|
|
CLAMP, Worm Gear |
2 |
|
|
| 12 |
8504541 |
|
|
|
PUMP ASSEMBLY |
1 |
811573 |
|
| 13 |
27-49110 |
|
|
|
GASKET, Circulating Water Pump Mount |
2 |
|
4,5 |
| 14 |
10-805611 |
|
|
|
SCREW, (.375-16 x 1.750) |
4 |
10-811574 |
|
| 15 |
19692T01 |
|
|
|
PULLEY, (7 In. Diameter) |
1 |
19692T |
|
| 16 |
57-48122Q |
|
|
|
BELT, (48 Inches) |
1 |
57-48122 |
|
| 17 |
10-47277 |
|
|
|
SCREW, (.312-24 x .750) |
4 |
|
|
| 18 |
850461001 |
|
|
|
HARMONIC BALANCER |
1 |
811555 |
(7.4L BRAVO) |
| 18 |
845625T2 |
|
|
|
DAMPER |
1 |
811556 |
(454 MAGNUM) |
| 19 |
90081T |
|
|
|
PULLEY |
1 |
|
|
| 20 |
10-75334 |
|
|
|
SCREW, (.375-24 x 3.00) |
3 |
|
This Part is NLA from Mercruiser.(7.4L BRAVO) |
| 20 |
10-358701 |
|
|
|
SCREW, (.375-16 x 2.00) |
3 |
|
(454 MAGNUM) |
| 21 |
13-35048 |
|
|
|
LOCKWASHER, (.375) |
3 |
|
|
| 22 |
|
|
|
|
WASHER |
3 |
|
|
| 23 |
|
|
|
|
SCREW, (.500-20 x 2.500) |
1 |
10-811559 |
|
| 24 |
12-49103 |
|
|
|
WASHER |
1 |
|
|
| 25 |
811570 |
|
|
|
COVER ASSEMBLY |
1 |
|
This Part is NLA from Mercruiser. |
| 26 |
26-8219471 |
|
|
|
SEAL |
1 |
|
4,5 |
| 27 |
27-811572 |
|
|
|
GASKET |
1 |
|
4,5 |
| 28 |
10-35366 |
|
|
|
SCREW, (.250-20 x .563) |
10 |
|
|
| - |
27-811547A92 |
|
|
|
GASKET SET, Engine |
1 |
|
(7.4L BRAVO) |
| - |
27-811572A92 |
|
|
|
GASKET SET, Overhaul |
1 |
|
This Part is NLA from Mercruiser.(454 MAGNUM) |
