| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
NSS |
|
|
|
|
NOT SOLD SEPARATE |
1 |
|
This part is not sold separate 1 |
| 2 |
22-48340 |
|
|
|
|
PLUG, (.250-18 x .41) (1/4 IN.) |
4 |
|
|
| 2 |
22-48358T |
|
|
|
|
PLUG, (.375) (3/8 IN.) |
2 |
22-48358 |
|
| 3 |
19-34270 |
|
|
|
|
EXPANSION PLUG, (1.625), Expansion (1-5/8 IN. DIA.) |
8 |
|
|
| 4 |
17-52190 |
|
|
|
|
PIN |
4 |
|
|
| 5 |
19-94140 |
|
|
|
|
EXPANSION PLUG |
1 |
|
|
| 6 |
23-85684 |
|
|
|
|
BEARING SET |
1 |
|
|
| 7 |
25-69756 |
|
|
|
|
O-RING, (.500 Inch) (1/2 IN.) |
1 |
25-811528 |
|
| 8 |
431-4734 |
|
|
|
|
CAMSHAFT |
1 |
|
|
| 9 |
845796T |
|
|
|
|
CHAIN |
1 |
811580 |
|
| 10 |
43-811578 |
|
|
|
|
SPROCKET |
1 |
|
|
| 11 |
43-845794T |
|
|
|
|
SPROCKET |
1 |
43-811579 |
|
| 12 |
10-845942 |
|
|
|
|
SCREW, (.312-18 x .750) |
3 |
10-35339 |
|
| 13 |
17-843378 |
|
|
|
|
PIN, Dowel (1/4 In. Diameter) (1/4 IN. DIA.) |
1 |
17-35312 |
|
| 14 |
811584 |
|
|
|
|
LIFTER |
16 |
|
|
| 15 |
22-48556 |
|
|
|
|
BUSHING , Reducer (.250 To .125) |
2 |
|
|
| 16 |
22-328022 |
|
|
|
|
PLUG, Pipe (.125-27) |
2 |
22-328021 |
|
| - |
806351R5 |
|
|
|
|
MARINE LONG BLOCK ENGINE |
1 |
807161A1 |
|
| - |
92-809825 |
|
|
|
|
RTV SILICONE, (3 Ounce Tube) Metallic Blue |
1 |
|
|
| - |
34227Q02 |
|
|
|
|
SEALING COMPOUND, (16 Ounce) |
1 |
92-342271 |
|
