575 SCi - Serial 0M900000 Thru 0M950526 - Driveshaft And Tailstock (Transmission)
Section Drawing: (Hover or click to view larger)
Other Sub-Sections:
- Circulating Water Pump And Front Cover
- Crankshaft - Piston And Coupler Components
- Cylinder Block And Camshaft
- Cylinder Head And Rocker Cover
- Distributor And Ignition Components
- Driveshaft And Tailstock (Transmission)
- Driveshaft Extension Components (Bravo)
- Electrical Components
- Exhaust Header - Tailpipe Assembly
- Flywheel Housing (Bravo Plug In)
- Flywheel Housing (Driveline)
- Flywheel Housing (Transmission)
- Fuel Pump And Fuel Cooler
- Gasket-Seal Set - Engine Overhaul (27-842182A1)
- Harness Assembly (EFI Wiring)
- Intake Manifold And Supercharger
- Intake Throttle Body Assembly
- Intake Throttle Body Components
- Monitor Assembly (Drive Lube)
- Mount Plates - Engine
- Oil Cooler (Transmission)
- Oil Cooler And Oil Filter (Engine)
- Oil Pan And Oil Pump
- Power-Assisted Steering Components (Design I)
- Power-Assisted Steering Components (Design II)
- Pump-Motor Assembly (865380A13)
- Pump-Motor Assembly (Design I - 14336A20)
- Pump-Motor Assembly (Design I - 14336A8)
- Pump-Motor Assembly (Design II - 14336A25)
- Pump-Motor Assembly (Design III - 14336A31)
- Reservoir Bottle (Transmission Fluid)
- Sea Water Pump Assembly
- Sender And Sensors
- Shift Bracket Components (Bravo Design I)
- Shift Bracket Components (Bravo Design II)
- Starter And Alternator Mounting
- Starter Assembly
- Thermostat Housing
- Transmission And Components (Driveline)
- Transmission And Components (Six Drive - Bravo)
- Trim Pump Assembly (14336 Series)
- Trim Pump Assembly (865380 Series)
- Water Hoses (Sea Water)
| Ref. | OEM Part # | Hardin # | Mallory # | GLM # | Other # | Description | Num Req. | Superceded From | Special Notes |
| 1 | 45-86978A3 | DRIVESHAFT ASSEMBLY, (39.940 Inches) | 1 | 45-86978A1 | |||||
| 2 | 61218 | FLANGE, Driveshaft | 1 | ||||||
| 3 | 61221T | CROSS AND BEARING, With Clips | 2 | ||||||
| 4 | 22-74036 | FITTING, Grease | 2 | ||||||
| 5 | 96276T4 | YOKE ASSEMBLY | 1 | 96276T2 | |||||
| 6 | 61218 | FLANGE, Driveshaft | 1 | ||||||
| 7 | 10-68743 | SCREW, (.437-20 x 1.250) | 4 | This Part is No Longer Available | |||||
| 8 | 13-47659 | LOCKWASHER, (.437) | 4 | ||||||
| 9 | 11-34933 | 676-9-72004 | NUT, (.437-20) Stainless Steel | 4 | 11-82671015 | ||||
| 10 | 847759 | ADAPTOR, Flange Yoke To Drive | 1 | ||||||
| 11 | 11-82670815 | NUT, (.437-20) | 4 | ||||||
| 12 | 10-805159 | SCREW, (.437-20 x 1.500) | 4 |
