| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
44187T |
|
|
|
|
HOUSING, Flywheel |
1 |
|
|
| 2 |
19-12304 |
|
|
|
|
PLUG, Timing Window |
1 |
|
|
| 3 |
10-35047 |
|
|
|
|
SCREW, (.375-16 x 1.250) Stainless Steel |
1 |
|
|
| 3 |
10-58642 |
|
|
|
|
SCREW, (.375-16 x 1.50) Stainless Steel |
2 |
|
|
| 3 |
10-68299 |
|
|
|
|
SCREW, (.375-16 x 3.00) Stainless Steel |
2 |
|
|
| 4 |
13-35048 |
|
|
|
|
LOCKWASHER, (.375) |
2 |
|
|
| 5 |
12-856774 |
|
|
|
|
WASHER, (.406 x .750 x .105) Stainless Steel |
6 |
|
|
| 5 |
12-20572 |
|
|
|
|
WASHER, (.390 x .750 x .093), For Slot |
1 |
|
|
| 6 |
54-78945 |
|
|
|
|
J CLAMP, Harness Support |
2 |
|
|
| 7 |
16-64066 |
|
|
|
|
STUD, (.375-16 x 2.750) Special |
2 |
|
|
| 8 |
11-32219 |
|
|
|
|
NUT, (.375-16) |
2 |
|
|
| 9 |
84-62826A7 |
|
|
|
|
CABLE ASSEMBLY, Ground - Black (21.00 Inches) |
1 |
|
This Part is No Longer Available |
| 9 |
84-62826A6 |
|
|
|
|
CABLE ASSEMBLY, Ground - Black (13.00 Inches) |
1 |
|
|
| 10 |
54-62494 |
|
|
|
|
CLIP, Hose |
1 |
|
|
| 11 |
19-38606 |
|
|
|
|
PLUG |
1 |
|
|
| 12 |
93911A4 |
|
|
|
|
HOUSING ASSEMBLY, Shaft Extension Support |
1 |
|
|
| 13 |
22-74036 |
|
|
|
|
FITTING, Grease |
2 |
|
|
| 14 |
10-825427 |
|
|
|
|
SCREW, (.437-14 x 1.250) |
6 |
|
|
| 15 |
12-45176 |
|
|
|
|
WASHER, (.453 x .812 x .105) |
6 |
|
|
| 16 |
939201 |
|
|
|
|
PLATE, Cover |
1 |
|
|
| 17 |
12-45176 |
|
|
|
|
WASHER, (.453 x .812 x .105) |
2 |
|
|
| 18 |
10-99204 |
|
|
|
|
SCREW, (.437-14 x 1.00) |
2 |
|
|
