| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superseded From |
Special Notes |
| 1 |
8M0059629 |
|
|
|
|
POWER STEERING PUMP |
1 |
|
|
| 2 |
21-8M0009629 |
|
|
|
|
CHECK VALVE ASSEMBLY |
1 |
|
|
| 3 |
8M0053444 |
|
|
|
|
PULLEY, Power Steering |
1 |
|
|
| 4 |
10-4010716 |
|
|
|
|
SCREW, (M8 x 16) |
4 |
|
|
| 5 |
10-849377 |
|
|
|
|
SCREW, (.312-24 x .750) Stainless Steel |
4 |
|
|
| 6 |
12-70132 |
|
|
|
|
WASHER, (.323 x .563 x .063) Stainless Steel |
4 |
|
|
| 7 |
8M8025216 |
|
|
|
|
BRACKET, Power Steering |
1 |
|
|
| 8 |
10-4010820 |
|
|
|
|
SCREW, (M10 x 20) Hex Flange - Stainless Steel |
AR |
|
|
| 9 |
10-885527105 |
|
|
|
|
SCREW, (M10 x 105) |
2 |
|
|
| 10 |
8M0045782 |
|
|
|
|
BRACKET, TENSIONER |
1 |
8M8025217 |
|
| 11 |
10-4008930 |
|
|
|
|
SCREW, (M8 x 30) Stainless Steel |
1 |
|
|
| 12 |
43-8183812 |
|
|
|
|
PINION STUD, (.437-20) Stainless Steel |
1 |
|
|
| 13 |
845117 |
|
|
|
|
BUSHING |
1 |
|
|
| 14 |
11-859135 |
|
|
|
|
NUT, (.437-20) Brass/Nickel Plated |
1 |
|
|
| 15 |
8M0046468 |
|
|
|
|
PULLEY, Idler |
1 |
|
|
| 16 |
10-88552620 |
|
|
|
|
SCREW, (M8 x 20) |
2 |
|
|
| 17 |
8M0000194 |
|
|
|
|
PULLEY, Crankshaft |
1 |
|
|
| 18 |
12-8M0043433 |
|
|
|
|
WASHER |
1 |
|
|
| 19 |
8M0030635 |
|
|
|
|
BELT, Oil Pump |
1 |
|
|
| 20 |
57-8M0038443 |
|
|
|
|
BELT, Accessory |
1 |
|
|
| 21 |
8M0062859 |
|
|
|
|
PULLEY |
1 |
885349500 |
|
| 22 |
8M0035152 |
|
|
|
|
PULLEY, 26 Teeth, Oil Pump |
1 |
|
|
| 23 |
865444T |
|
|
|
|
PULLEY, (3.50 Inch Diameter) |
1 |
|
|
| 24 |
11-859135 |
|
|
|
|
NUT, (.437-20) Brass/Nickel Plated |
1 |
|
|
