| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
807962A15 |
|
|
|
|
SHIFT BRACKET ASSEMBLY |
1 |
99237A10 |
|
| 2 |
16-865154A02 |
|
|
|
|
STUD, SHIFT CABLE |
1 |
16-98798 |
|
| 3 |
13051A4 |
|
|
|
|
LEVER ASSEMBLY, ACTUATING |
1 |
|
This Part is No Longer Available |
| 4 |
24-862850 |
|
|
|
|
SPRING, ACTUATING LEVER |
1 |
24-45599 |
|
| 5 |
10-13743 |
|
|
|
|
SHOULDER SCREW, LEVER |
1 |
|
|
| 6 |
18-328571 |
|
|
|
|
COTTER PIN, SHIFT CABLE RETAINING |
1 |
18-32857 |
|
| 7 |
24-98880 |
|
|
|
|
SPRING, SHIFT CABLE STUD |
1 |
|
|
| 8 |
12-56720 |
|
|
|
|
WASHER, SHIFT BRACKET STUD |
1 |
|
|
| 9 |
16-987981 |
|
|
|
|
SPACER, SHIFT CABLE STUD |
1 |
23-98820 |
|
| 10 |
12-35462 |
|
|
|
|
WASHER, SHIFT CABLE STUD |
3 |
|
|
| 11 |
11-8267119 |
|
|
|
|
NUT, SHIFT CABLE STUD |
2 |
11-13438 |
|
| 12 |
16-96112 |
|
|
|
|
STUD, SHIFT CABLE |
1 |
|
|
| 13 |
11-63341 |
|
|
|
|
TEE NUT, SHIFT CABLE STUD |
1 |
|
|
| 14 |
13898T06 |
|
|
|
|
SHIFT LEVER ASSEMBLY |
1 |
13898A3 |
|
| 15 |
10-13743 |
|
|
|
|
SHOULDER SCREW, SHIFT LEVER |
1 |
|
|
| 16 |
17-68402 |
|
|
|
|
SHOULDER PIN, SHIFT LEVER |
1 |
|
|
| 17 |
18-210711 |
|
|
|
|
COTTER PIN, SHIFT LEVER |
1 |
18-21071 |
|
| 18 |
39670A28 |
|
|
|
|
SWITCH ASSEMBLY, CUT-OUT |
1 |
|
This Part is No Longer Available |
| 19 |
10-30902 |
|
|
|
|
SCREW, SWITCH TO SHIFT BRACKET |
2 |
|
|
| 20 |
86-66986 |
|
|
|
|
TERMINAL BLOCK |
1 |
|
This Part is No Longer Available |
| 21 |
10-96113 |
|
|
|
|
SCREW, TERMINAL BLOCK (7/8") |
1 |
|
|
| 22 |
10-73287 |
|
|
|
|
SCREW, TERMINAL BLOCK (3/8") |
1 |
|
|
| 23 |
13-26996 |
|
|
|
|
LOCKWASHER, TERMINAL BLOCK SCREW |
2 |
|
|
