| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| - |
1686-827214T23 |
|
|
|
|
GEAR HOUSING ASSEMBLY, Complete |
1 |
|
No Longer Available |
| 1 |
1686-827214T25 |
|
|
|
|
GEAR HOUSING ASSEMBLY, Basic |
1 |
827214T16 |
|
| 47 |
89594A1 |
|
|
|
|
FOLLOWER ASSEMBLY |
1 |
|
|
| 48 |
789562 |
|
|
|
|
SHIFT CAM |
1 |
|
|
| 49 |
79911A1 |
|
|
|
|
ROD |
1 |
|
|
| 50 |
17-8M0084245 |
|
|
|
|
PIN |
1 |
78906 |
|
| 51 |
24-79910 |
|
|
|
|
SPRING |
2 |
|
|
| 52 |
12-78910 |
|
|
|
|
WASHER |
AR |
|
|
| 53 |
15-47397A1 |
|
|
|
|
SHIM SET |
AR |
|
|
| 54 |
31-78172A1 |
|
|
|
|
BEARING ASSEMBLY, Tapered Roller |
1 |
|
|
| 55 |
43-44104A7 |
|
|
|
|
GEAR SET |
1 |
|
|
| 56 |
31-549281 |
|
|
|
|
BEARING, Roller |
1 |
|
|
| 57 |
52-42672T |
|
|
|
|
RATCHET |
1 |
|
|
| 58 |
17-42671 |
|
|
|
|
PIN, Cross |
1 |
|
|
| 59 |
17-78909 |
|
|
|
|
PIN, Detent |
2 |
|
|
| 60 |
24-78962 |
|
|
|
|
SPRING |
2 |
|
|
| 61 |
44-840451A03 |
|
|
|
|
PROPELLER SHAFT |
1 |
840451A2 |
|
| - |
840389K06 |
|
|
|
|
HUB KIT |
1 |
840389K5 |
|
| - |
840382A02 |
|
|
|
|
SNUBBER STRIP KIT |
1 |
840382A1 |
|
| 62 |
43-822824A1 |
|
|
|
|
GEAR ASSEMBLY, Reverse |
1 |
|
|
| 63 |
23-822823 |
|
|
|
|
THRUST RING |
1 |
|
|
| 64 |
681001 |
|
|
|
|
RING, Thrust |
1 |
|
|
| 65 |
30-88957T |
|
|
|
|
BEARING, Ball |
1 |
|
|
| 66 |
25-31534 |
|
|
|
|
O-RING |
1 |
|
|
| 67 |
848840A1 |
|
|
|
|
CARRIER ASSEMBLY, Bearing |
1 |
848840T1 |
|
| 68 |
31-817072 |
|
|
|
|
BEARING, Roller |
1 |
|
|
| 69 |
53-817071 |
|
|
|
|
RING, Snap |
1 |
|
|
| 70 |
26-815565 |
|
|
|
|
SEAL, Oil |
2 |
|
|
| 71 |
28-30281 |
|
|
|
|
KEY |
1 |
|
|
| 72 |
14-79447 |
|
|
|
|
TAB WASHER |
1 |
|
|
| 73 |
8M2011027 |
|
|
|
|
RETAINER |
1 |
79448 |
|
| 74 |
13-423511 |
|
|
|
|
LOCKWASHER, Toothed |
1 |
|
|
| 75 |
11-52707Q1 |
|
|
|
|
PROP NUT KIT, (.750-16) |
1 |
|
|
| 76 |
832066A1 |
|
|
|
|
PLATE KIT, Water Inlet |
1 |
|
|
| 77 |
10-188642 |
|
|
|
|
SCREW, (#8-32 x .500) |
4 |
|
|
| 78 |
97-76214Q5 |
|
|
|
|
ANODE KIT |
1 |
|
|
| 79 |
10-66024 |
|
|
|
|
SCREW, (.437-14 x 1.75) |
1 |
|
|
| 80 |
11-859116 |
|
|
|
|
NUT, (.437-20) |
2 |
|
|
| 81 |
10-30206 |
|
|
|
|
SCREW, (.375-16 x 1.00) Stainless Steel |
1 |
|
|
| 82 |
12-822836 |
|
|
|
|
WASHER, (.445 x .805 x .108) |
2 |
|
|
| 83 |
22-881866 |
|
|
|
|
FITTING |
1 |
859432 |
|
| 84 |
32-85944975 |
|
|
|
|
TUBING, (72.00 Inches Bulk) (Cut to 7 IN.) |
1 |
|
|
| - |
26-89238A3 |
|
|
|
|
SEAL KIT, Gear Housing |
1 |
|
|
