| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
21-8781051 |
|
|
|
|
CHECK VALVE |
1 |
|
|
| 2 |
22-424254 |
|
|
|
|
FITTING |
1 |
|
|
| 3 |
32-8M0108355 |
|
|
|
|
HOSE, (57.00 Inches Bulk) (Cut to 6.00 Inch Length) |
1 |
830756109 |
|
| 4 |
NSS |
|
|
|
|
Cap |
2 |
|
Not Sold Separate |
| 5 |
32-875289 |
|
|
|
|
HOSE |
1 |
|
|
| 6 |
22-858955 |
|
|
|
|
CONNECTOR |
2 |
|
|
| 7 |
35-875284T01 |
|
|
|
|
FILTER, Oil - In Line |
1 |
875284001 |
|
| 8 |
32-875283 |
|
|
|
|
HOSE, (2.00 Inches) |
1 |
|
|
| 9 |
54-816311T |
|
|
|
|
TIE STRAP, (8.00 Inches) |
AR |
|
|
| 9 |
69355 |
|
|
|
|
TIE STRAP, (5.50 Inches) |
AR |
|
|
| 9 |
56762 |
|
|
|
|
TIE STRAP, (4.00 Inches) |
AR |
|
|
| 10 |
32-892830053 |
|
|
|
|
HOSE, (24.00 Inches Braided) |
1 |
|
|
| 11 |
32-8M0054152 |
|
|
|
|
TUBING, (38.00 Inches Bulk) (Cut to 21.00 Inch Length) |
1 |
85606065 |
|
| 12 |
32-828547753 |
|
|
|
|
CONDUIT, (.750 Inside Diameter x 3.00 Feet Bulk) (Cut to 10.00 Inch Length) (Use Where Applicable) |
1 |
|
|
| 13 |
8M0063190 |
|
|
|
|
RESERVOIR ASSEMBLY |
1 |
833069T9 |
|
| 14 |
NSS |
|
|
|
|
Decal |
1 |
|
Not Sold Separate |
| 15 |
25-855362001 |
|
|
|
|
GROMMET |
3 |
855362 |
|
| 16 |
12-49436 |
|
|
|
|
WASHER |
3 |
|
|
| 17 |
10-60411 |
|
|
|
|
SCREW, (.312-18 x 1.250) |
3 |
|
|
| 18 |
10-855634 |
|
|
|
|
SCREW |
3 |
|
No Longer Available |
| 19 |
87-856156T02 |
|
|
|
|
SWITCH ASSEMBLY |
1 |
856156A2 |
|
| 20 |
10-58376 |
|
|
|
|
SCREW, (.164-18 x .375) |
1 |
|
|
| 21 |
12-72761 |
|
|
|
|
WASHER, (.203 x .562 x .060) Stainless Steel |
1 |
|
|
| - |
809430T02 |
|
|
|
|
POWERHEAD ASSEMBLY |
1 |
|
|
