Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
1 |
3518-832937A06 |
|
|
|
|
HOUSING ASSEMBLY, Driveshaft |
1 |
832937A3 |
|
1 |
3519-832938A06 |
|
|
|
|
HOUSING ASSEMBLY, Driveshaft |
1 |
832938A5 |
|
2 |
16-8M0008031 |
|
|
|
|
STUD, (M12 x 52) |
4 |
856983 |
|
3 |
10-892860 |
|
|
|
|
SCREW, (M12 x 35), Internal Hex |
1 |
4009135 |
|
3 |
10-857136 |
|
|
|
|
SCREW, (M12 x 35 MM), External Hex |
1 |
|
|
4 |
25-8331231 |
|
|
|
|
GROMMET |
1 |
|
|
5 |
12-4002321 |
|
|
|
|
WASHER, (12.80 mm x 24.0 mm x 2.4 mm) Stainless Steel |
4 |
|
|
6 |
11-4013812 |
|
|
|
|
NUT, (M12) Stainless Steel |
4 |
|
|
7 |
19-64649 |
|
|
|
|
PLUG |
1 |
|
|
8 |
10-898834 |
|
|
|
|
SCREW, (M14 x 178) |
2 |
815431 |
|
9 |
88238A10 |
|
|
|
|
CABLE ASSEMBLY, Ground |
2 |
|
|
10 |
12-815432 |
|
|
|
|
WASHER, (.562 x 2.00 x .125) |
2 |
|
|
11 |
8M0055931 |
|
|
|
|
MOUNT |
2 |
840361 |
|
12 |
12-825190 |
|
|
|
|
WASHER |
4 |
|
|
13 |
11-896602 |
|
|
|
|
NUT |
2 |
815434 |
|
14 |
8186442 |
|
|
|
|
CLAMP |
2 |
|
No Longer Available |
15 |
10-84036240 |
|
|
|
|
SCREW, (M8 x 40) |
4 |
|
No Longer Available |
16 |
12-847541 |
|
|
|
|
WASHER |
4 |
|
|
17 |
8M0001136 |
|
|
|
|
COVER, Black |
2 |
818645F1 |
No Longer Available |
18 |
10-69079 |
|
|
|
|
SCREW, (#10-16 x .440) |
2 |
|
|
19 |
8329321 |
|
|
|
|
SEAL |
1 |
|
|
20 |
833116A11 |
|
|
|
|
TUBE ASSEMBLY, Exhaust |
1 |
|
No Longer Available |
20 |
833116A4 |
|
|
|
|
TUBE ASSEMBLY, Exhaust |
1 |
|
|
21 |
NSS |
|
|
|
|
Strainer |
1 |
|
Not Sold Separate |
22 |
10-81893435 |
|
|
|
|
SCREW, (M8 x 35) |
4 |
|
|
23 |
32-8M0042785 |
|
|
|
|
TUBE, Water |
1 |
8329417 |
|
23 |
32-8M0042786 |
|
|
|
|
TUBE, Water |
1 |
8329418 |
|
23 |
32-8M0042787 |
|
|
|
|
TUBE, Water |
1 |
8329419 |
|
24 |
832940001 |
|
|
|
|
SEAL |
1 |
832940 |
|
25 |
8329391 |
|
|
|
|
CLAMP |
1 |
|
|
26 |
10-41508 |
|
|
|
|
SCREW, (.250-20 x .500) Stainless Steel |
1 |
|
|
27 |
8M0105088 |
|
|
|
|
SPACER |
1 |
823979T1 |
|
28 |
17-43044 |
|
|
|
|
PIN, Dowel - Without Hole (.375 x .625) |
2 |
|
|
29 |
16-8M0008047 |
|
|
|
|
STUD, (M12 x 179) |
4 |
857009 |
|
30 |
10-857137 |
|
|
|
|
SCREW, (M12 x 160) |
1 |
|
|
31 |
10-81893435 |
|
|
|
|
SCREW, (M8 x 35) |
2 |
|
|
32 |
13-72521 |
|
|
|
|
LOCKWASHER, Internal Tooth |
1 |
|
|
