| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Description |
Num Req. |
Superseded From |
Special Notes |
| 1 |
32-8M0062666 |
|
|
|
HOSE, (96.00 Inches Bulk) |
1 |
32-865672079 |
(Cut to Fit) |
| 2 |
54-815504228 |
|
|
|
CLAMP, Worm Gear |
AR |
|
|
| 3 |
32-8M2017358 |
|
|
|
HOSE, Sea Water Pump to Fitting |
1 |
|
|
| 4 |
54-815504222 |
|
|
|
CLAMP, Worm Gear (1.98 DIameter) |
2 |
|
|
| 5 |
32-8M2018801 |
|
|
|
HOSE, Water Orifice to Power Steering Cooler |
1 |
|
|
| 6 |
32-8M0062634 |
|
|
|
HOSE, (44.00 Inches Bulk), Drain to Y-Fitting |
1 |
32-4285069 |
(Cut to 8 Inches) |
| 7 |
54-815504216 |
|
|
|
CLAMP, Worm Gear (1.56 Diameter) |
1 |
|
|
| 8 |
54-815504212 |
|
|
|
CLAMP, Worm Gear |
AR |
|
|
| 9 |
54-815504232 |
|
|
|
CLAMP, Worm Gear (2.50 Diameter) |
1 |
|
|
| 10 |
32-8M2018756 |
|
|
|
HOSE, Heat Exchanger to Poppet |
1 |
|
|
| 11 |
54-815504220 |
|
|
|
CLAMP, Worm Gear |
1 |
|
|
| 12 |
8M0045363 |
|
|
|
HOSE ASSEMBLY, 3 Bib Orifice Meter |
1 |
|
|
| 13 |
32-8M0062635 |
|
|
|
HOSE, (42 Inches), Water |
1 |
32-8M2019902 |
|
| 14 |
19-858240 |
|
|
|
CAP |
1 |
22-861427 |
|
| 15 |
22-865324 |
|
|
|
QUICK CONNECT |
2 |
|
|
| 15 |
22-865324 |
|
|
|
QUICK CONNECT |
1 |
|
SeaCore Flush |
| 16 |
32-8M0062666 |
|
|
|
HOSE, (96.00 Inches Bulk) |
1 |
32-865672079 |
(Cut to 14.50) |
| 17 |
22-865362 |
|
|
|
QUICK CONNECT |
1 |
|
|
| 18 |
22-8M4501756 |
|
|
|
FITTING |
1 |
|
SeaCore |
| 19 |
54-815504212 |
|
|
|
CLAMP, Worm Gear |
1 |
|
|
| 20 |
22-857175 |
|
|
|
FITTING |
1 |
22-861405 |
|
| 21 |
22-861406 |
|
|
|
SOCKET |
1 |
|
|
| 22 |
54-815504206 |
|
|
|
CLAMP, Worm Gear |
2 |
|
|
| 23 |
32-8M0062669 |
|
|
|
HOSE, (45 Inches Bulk) |
1 |
32-8M2012906 |
(Cut to Fit) |
