| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
48504T2 |
|
|
|
|
ADAPTOR-Oil Filter |
1 |
48504A2 |
|
| 2 |
10-34353 |
|
|
|
|
SCREW (3/8-16 x 1")-Adaptor to Bracket |
2 |
|
|
| 3 |
13-35048 |
|
|
|
|
LOCKWASHER (3/8")-Adaptor Screw |
2 |
|
|
| 4 |
12-20553 |
|
|
|
|
WASHER-Oil Filter Adaptor Screw |
2 |
|
|
| 5 |
63880T |
|
|
|
|
BRACKET-Oil Filter |
1 |
|
|
| 6 |
22-805632 |
|
|
|
|
CONNECTOR |
1 |
|
|
| 7 |
27-91892 |
|
|
|
|
GASKET-Adaptor Cover and Oil Filter |
3 |
|
6 |
| 8 |
35-16595Q |
|
|
|
|
FILTER-Oil |
1 |
35-16595 |
|
| 9 |
10-47462 |
|
|
|
|
SCREW (7/16-14 x 1-1/4")-Bracket to Engine |
3 |
|
|
| 9 |
10-37612 |
|
|
|
|
SCREW (3/8-16 x 1-1/4")-Bracket to Engine |
1 |
|
|
| 10 |
13-35048 |
|
|
|
|
LOCKWASHER (3/8")-Bracket Screw |
1 |
|
|
| 10 |
13-32993 |
|
|
|
|
LOCKWASHER (7/16")-Bracket Screw |
3 |
|
|
| 11 |
90783A22 |
|
|
|
|
ADAPTOR ASY-Oil Filter |
1 |
|
SERIAL 0C849992-0D725646 |
| 12 |
22-805632 |
|
|
|
|
CONNECTOR |
1 |
|
|
| 13 |
91830 |
|
|
|
|
COVER-Adaptor |
1 |
|
SERIAL 0C849992-0D725646 |
| 13A |
35-818400A1 |
|
|
|
|
ADAPTOR KIT |
1 |
|
SERIAL 0D725647-0F213244 |
| 14 |
10-91966 |
|
|
|
|
SCREW (5/16-18 x 4")-Oil Filter Adaptor |
1 |
|
This Part is No Longer Available No longer made, limited availability |
| 14 |
10-91967 |
|
|
|
|
SCREW (5/16-18 x 3-1/2")-Oil Filter Adaptor |
1 |
|
This Part is No Longer Available No longer made, limited availability |
| 15 |
27-99893 |
|
|
|
|
GASKET-Oil Filter Adaptor |
1 |
|
No longer made, limited availability 6 |
| 16 |
99889 |
|
|
|
|
VALVE-By Pass |
1 |
|
|
| 17 |
22-63825 |
|
|
|
|
ELBOW-Oil Hose |
1 |
|
|
| 18 |
22-48246 |
|
|
|
|
ELBOW-Oil Hose |
1 |
|
|
| 19 |
32-9235738 |
|
|
|
|
HOSE ASSY-Oil (18-1/2") |
2 |
|
SERIAL 0C849992-0D725646 |
| 19A |
32-9235751 |
|
|
|
|
HOSE ASSY-Oil (26") |
1 |
|
SERIAL 0D725647-0F213244 |
| 20 |
22-54035 |
|
|
|
|
ELBOW (905) |
1 |
|
This Part is No Longer Available |
| 21 |
87-94009 |
|
|
|
|
SWITCH-Choke Pressure |
1 |
|
|
| 22 |
84-79139A21 |
|
|
|
|
CABLE ASSEMBLY (RED) (15") |
1 |
|
This Part is No Longer Available |
| 23 |
816074T |
|
|
|
|
COOLER-Oil |
1 |
816074 |
|
| - |
817043 |
|
|
|
|
END CAP |
2 |
|
|
| - |
27-817042 |
|
|
|
|
GASKET |
2 |
|
|
| - |
8M0039163 |
|
|
|
|
O RING |
2 |
25-814878 |
|
| - |
10-816767 |
|
|
|
|
SCREW |
2 |
|
|
| 24 |
8161951 |
|
|
|
|
BRACKET-Oil Cooler (Bravo Models) |
1 |
|
This Part is No Longer Available |
| 24 |
12820 |
|
|
|
|
BRACKET-Oil Cooler (Power Steering Models) |
1 |
|
|
| 25 |
8161961 |
|
|
|
|
BRACKET-Oil Cooler (Bravo Models) |
1 |
|
|
| 25 |
12820 |
|
|
|
|
BRACKET-Oil Cooler (Power Steering Models) |
1 |
|
|
| 26 |
56328A1 |
|
|
|
|
BRACKET-Oil Cooler |
2 |
|
|
| 27 |
10-34353 |
|
|
|
|
SCREW (3/8-16 x 1") |
1 |
|
|
| 28 |
13-35048 |
|
|
|
|
LOCKWASHER (3/8") |
1 |
|
|
| 29 |
12-20553 |
|
|
|
|
WASHER |
1 |
|
|
| 30 |
10-49668 |
|
|
|
|
SCREW (1/4-20 x 3/4") (Bravo Models) |
4 |
|
|
| 30 |
10-60300 |
|
|
|
|
SCREW (1/4-28 x 3/4") (Power Steering Models) |
4 |
|
|
| 31 |
13-26992 |
|
|
|
|
LOCKWASHER (1/4") (Bravo Models) |
4 |
|
|
| 32 |
54-15095 |
|
|
|
|
J CLAMP |
1 |
|
|
| 33 |
22-63825 |
|
|
|
|
ELBOW (905) |
2 |
|
|
| 34 |
32-9235753 |
|
|
|
|
HOSE ASSEMBLY-Oil (28") |
1 |
|
|
| 35 |
32-9235749 |
|
|
|
|
HOSE ASSEMBLY-Oil (24") |
1 |
|
SERIAL 00000000-6470F213 |
| 36 |
22-821914 |
|
|
|
|
FITTING-Filter Adaptor |
1 |
|
This Part is No Longer Available SERIAL 0D725647-0F213244 |
| 37 |
12-55822 |
|
|
|
|
WASHER |
1 |
|
SERIAL 0D725647-0F213244 |
| 38 |
25-90196 |
|
|
|
|
O RING-Filter Adaptor |
1 |
|
SERIAL 0D725647-0F213244 |
| 39 |
11-30506 |
|
|
|
|
NUT (1/4-28) (Power Steering Models) |
4 |
|
|
| 40 |
27-815669A90 |
|
|
|
|
COMPONENT OF GASKET SET |
- |
|
This Part is No Longer Available |
| 41 |
27-811546A98 |
|
|
|
|
COMPONENT OF GASKET SET |
- |
27-811546A93 |
This Part is No Longer Available |
