| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
45-86978A3 |
|
|
|
|
DRIVESHAFT ASSEMBLY (36.940 In.) |
1 |
45-86978A1 |
|
| 1 |
45-53967A1 |
|
|
|
|
DRIVESHAFT ASSEMBLY (43.625 In.) |
1 |
|
This Part is No Longer Available |
| 2 |
61218 |
|
|
|
|
FLANGE-Driveshaft |
1 |
|
|
| 3 |
61221T |
|
|
|
|
UNIVERSAL JOINT KIT |
2 |
61221 |
|
| 4 |
22-74036 |
|
|
|
|
FITTING-Grease |
2 |
|
|
| 5 |
96276T4 |
|
|
|
|
YOKE ASSEMBLY |
1 |
96276A2 |
|
| 6 |
61218 |
|
|
|
|
FLANGE |
1 |
|
|
| 7 |
10-68743 |
|
|
|
|
SCREW (.437-20 x 1.250) |
4 |
|
This Part is No Longer Available |
| 8 |
12-861854 |
|
|
|
|
WASHER |
4 |
12-91964 |
|
| 9 |
11-34933 |
|
676-9-72004 |
|
|
NUT (.437-20) |
4 |
|
|
| - |
52513A3 |
|
|
|
|
TAILSTOCK ASSEMBLY |
1 |
|
This Part is No Longer Available |
| 10 |
52505A1 |
|
|
|
|
SHAFT ASSEMBLY-Driveshaft Extension |
1 |
|
This Part is No Longer Available |
| 11 |
19-47463 |
|
|
|
|
PLUG |
1 |
|
|
| 12 |
23-47471T |
|
|
|
|
BEARING |
1 |
23-47471 |
|
| 13 |
10-60106 |
|
|
|
|
SCREW (.437-20 x 1.250) |
4 |
|
This Part is No Longer Available |
| 14 |
12-45176 |
|
|
|
|
WASHER |
4 |
|
|
| 15 |
55434A2 |
|
|
|
|
HOUSING ASSY-Driveshaft Extension |
1 |
|
This Part is No Longer Available |
| 16 |
26-52499 |
|
|
|
|
SEAL-Oil |
1 |
|
|
| 17 |
22-36382 |
|
|
700-21887 |
|
PLUG-Pipe (.250) |
1 |
|
|
| 18 |
22-328022 |
|
|
|
|
PLUG-Pipe (.125) |
1 |
22-32802 |
3 |
| 19 |
22-47902 |
|
|
|
|
FITTING |
1 |
|
|
| 20 |
15-49264A1 |
|
|
|
|
SHIM SET-Driveshaft Extension Housing |
1 |
|
This Part is No Longer Available no longer made, limited availability |
| 21 |
30-47470 |
|
|
|
|
BEARING-Ball |
1 |
|
|
| 22 |
53-52502 |
|
|
|
|
RING-Snap |
1 |
|
|
| 23 |
27-52501 |
|
|
|
|
GASKET |
1 |
|
|
| 24 |
52506A1 |
|
|
|
|
HOUSING ASSEMBLY-Bearing Support |
1 |
|
This Part is No Longer Available |
| 25 |
31-47468T |
|
|
|
|
BEARING-Needle |
1 |
31-47468 |
This Part is No Longer Available |
| 26 |
26-47465 |
|
|
|
|
SEAL-Oil |
1 |
|
|
| 27 |
53-52507 |
|
|
|
|
RING-Support |
1 |
|
This Part is No Longer Available |
| 28 |
53-52503 |
|
|
|
|
RING-Snap |
1 |
|
This Part is No Longer Available |
| 29 |
24-47755 |
|
|
|
|
SPRING-Yoke Guide |
1 |
|
|
| 30 |
10-56393 |
|
|
|
|
SCREW (.437-20 x 1.750) |
2 |
|
|
| 30 |
10-32695 |
|
|
|
|
SCREW (.437-20 x 2.250) |
4 |
|
|
| 30 |
10-32515 |
|
|
|
|
SCREW (.437-20 x 2.500) |
2 |
|
|
| 31 |
12-22248 |
|
|
|
|
WASHER |
8 |
|
|
| 32 |
11-35053 |
|
|
|
|
NUT (.437-20) |
8 |
|
|
